Nickel Beryllium Copper Alloy Bars SAE 463

Nickel Beryllium Copper Alloy Bars SAE 463

For more information, please contact our representative. Thank you! The most reliable copper alloy material partner that

Send your inquiry

DESCRIPTION

Basic Info
Model NO. C17510
HS Code 7407101000
Production Capacity 10tons/Month
Product Description
Nickel Cobalt Beryllium Copper (C17510)
Chemical composition(%)CoNiBeCu
0.31.4-2.20.2-0.6Balance
Material Characteritics
High thermal and electrical conductivity
Good strength and hardness
High tensile strenght
Very high hardness
Typical applications
Electrodes for spot welding, especially for stainless steel
Electrodes for projection welding
Butt welding jaws
Contact tips for submerged-arc-welding
Plunger tips for horizontal die casting machines
Moulds for NF-metal castings
Welding equipments
Current carry shafts
Plastic injection mold tooling
Robotics
Current carry bushings
Fabrication properties
TechniqueSuitability
Soldering Good
BrazingGood
Oxyacetylene weldingNot recommended
Gas shielded Arc weldingFair
Coated metal Arc weldingFair
Spot weldGood
Seam weldFair
Butt weldFair
Capacity for being cold workedExcellent
Capactiy for being hot formedGood
Machinability rating 40
Common fabrication processes
Blanking
Drilling
Forming
Bending
Tapping
Turning
Introduction to Nickel Cobalt Berrylium Copper(C17510)
Cobalt Beryllium Copper is primarily used in the industry applications that require most highly thermal or electrical conductivity, which features a cobalt alloying addition (2.40-2.70%). C17500 also Offers good strength and hardness characteristics plus conductivity in the range of 45-60 percent of copper with ultimate tensile and hardness properties approaching 140 ksi and RB 100 respectively.


For more information, please contact our representative. Thank you!
The most reliable copper alloy material partner that you can always count on !
